AMPLIFIER DOMINANCE

AZ-2U-1120

Commercial Amplifier - 1 zone

Overview

Clear Audio Quality

Separate volume control for each zone
Bluetooth connectivity
Two speaker connection options: transformer or standard 4-16Ω
connection
Separate bass and treble control
CLASS AB amplifier
2 microphone inputs
Overheating protection
LED digital display
RCA AUX input
RCA output
Separate volume control for each microphone

Tech Specs

Maximum Power Output: 120W
Output: 4-16Ω Balance output
100V rated output voltage
Inputs: MIC 1, 2, 35MV/600Ω (-10dB imbalance)
AUX: 0.775X/10K (0dB)
Backup Power Input: 24VDC
Frequency Response: 70Hz-18KHz(±3dB)
THD: 0.1% at 1KHz, 1/3 Related power
Signal To Noise Ratio: Mic 1, 2: ≥ 66dB, AUX 1: ≥70dB
Volume: Bass: ±10dB@100Hz;
B Treble: ±10dB@10KHz
Clipping: Short-circuit protection, overload protection
Power: AC-220V-240V/50Hz
Size: 48.2 x 31 x 8.8 cm
N.W: 11.3 kg

Technical specs are subject to change without notice
